Pumps for civil drainage and purification

The range is designed and built to be used in all demanding applications, where reliability plays the most important role.

pump detail

H2

electropumps with twin and quad-channel

H2

The H Series is used to pump clear water or light sewage where high pressure is needed. This series particularly suited to pumping water for fountains, waterparks, agricultural irrigation and farming.

Technical data

ImpellerTwin and quad-channel
Flanged outputG2″ – DN65
PerformanceHmax 47m, Qmax 65 m³/h
Power1,5 – 7,5 kW
VersionsMonophase/Threephase
Main componentsCast iron GG25
ATEX certification

Performance Overview

campo prestazione h2

Data sheet

Details

The HT double-channel impeller are suitable for pumping very high pressure with free passage of solids up to 17 mm.

Pumps with explosion proof available on request.

0477EPT 17 ATEX 2702 X
II 2 GEx db IIB T4 Gb
Ex h IIB T4 Gb
0° ≤ Ta ≤ 40°

The seal leak detector is certified according to the norm ATEX EN 60079-0, EN 60079-1 (through safety barrier) and fitted standard on all series.

The cable gland is made of stainless steel AISI 316 and certified according to the norm ATEX EN 60079-0, EN 60079-1. Standard on all series.
